SQL Server Scheduled Email Queries

Every once in a while I come across a problem that both surprises me that it exists and that the solution is often trivial. This is one of those. Basically developer at a client wanted to setup a scheduled task that would execute a query and email the results. Everything appeared to work, but the emails never went out. There were no errors that were obvious other than the emails never arrived. Some digging via profiler showed that the SQL Agent user was having permission issues. But basically giving it every permission possible didn’t solve it.

So let me walk you through it. First, let’s create a real simple stored procedure. This assumes you have AdventureWorks2014 installed (yeah, it’s old, but it’s what I had handy).

Use adventureworks2014
GO
Create or Alter Procedure Send_Test_Email
as
exec msdb.dbo.sp_send_dbmail @recipients=’test@example.com’, @body=’This is the body of the email’, @subject=’Test Email w query embedded’,
@query=’select * from adventureworks2014.sales.SalesOrderHeader where subtotal > 150000′;

Now, here’s an important detail I did discover during testing. If my query didn’t actually query a table, but instead was say @query=’select getdate()’ things worked fine.

That said, if you simply execute the query above in SSMS, it should work just fine. (I’d recommend you put your own email in it for testing. This way you’ll know if the email is actually being sent.)

Before you do that, also create the following stored procedure:

Use adventureworks2014
GO
Create or Alter Procedure Send_Test_Email_Query_attached
as
exec msdb.dbo.sp_send_dbmail @recipients=’test@example.com’, @body=’This is the body of the email’, @subject=’Test Email w query embedded’,
@query=’select * from adventureworks2014.sales.SalesOrderHeader where subtotal > 150000′,
@attach_query_result_as_file = 1,
@query_result_no_padding = 1,
@query_attachment_filename = ‘Sales Report.csv’,
@query_result_separator = ‘;’,
@exclude_query_output = 1,
@append_query_error = 0,
@query_result_header = 0

This will execute the same query as the original stored procedure, but place the contents in a CSV file as an attachment.

Again, if you execute the above directly from SSMS, you should receive the email without an issue. This is basically what the client was attempting to do.

Now create the following job:

USE [msdb]
GO

/ Object: Job [Send AdventureWorks Email] Script Date: 7/27/2021 9:12:49 AM / BEGIN TRANSACTION DECLARE @ReturnCode INT SELECT @ReturnCode = 0 / Object: JobCategory [[Uncategorized (Local)]] Script Date: 7/27/2021 9:12:49 AM /
IF NOT EXISTS (SELECT name FROM msdb.dbo.syscategories WHERE name=N'[Uncategorized (Local)]’ AND category_class=1)
BEGIN
EXEC @ReturnCode = msdb.dbo.sp_add_category @class=N’JOB’, @type=N’LOCAL’, @name=N'[Uncategorized (Local)]’
IF (@@ERROR <> 0 OR @ReturnCode <> 0) GOTO QuitWithRollback

END

DECLARE @jobId BINARY(16)
EXEC @ReturnCode = msdb.dbo.sp_add_job @job_name=N’Send AdventureWorks Email’,
@enabled=1,
@notify_level_eventlog=0,
@notify_level_email=0,
@notify_level_netsend=0,
@notify_level_page=0,
@delete_level=0,
@description=N’No description available.’,
@category_name=N'[Uncategorized (Local)]’,
@owner_login_name=N’sa’, @job_id = @jobId OUTPUT
IF (@@ERROR <> 0 OR @ReturnCode <> 0) GOTO QuitWithRollback
/ Object: Step [Send email] Script Date: 7/27/2021 9:12:50 AM /
EXEC @ReturnCode = msdb.dbo.sp_add_jobstep @job_id=@jobId, @step_name=N’Send email’,
@step_id=1,
@cmdexec_success_code=0,
@on_success_action=1,
@on_success_step_id=0,
@on_fail_action=2,
@on_fail_step_id=0,
@retry_attempts=0,
@retry_interval=0,
@os_run_priority=0, @subsystem=N’TSQL’,
@command=N’exec Send_test_email_Query_attached’,
@database_name=N’adventureworks2014′,
@flags=0
IF (@@ERROR <> 0 OR @ReturnCode <> 0) GOTO QuitWithRollback
EXEC @ReturnCode = msdb.dbo.sp_update_job @job_id = @jobId, @start_step_id = 1
IF (@@ERROR <> 0 OR @ReturnCode <> 0) GOTO QuitWithRollback
EXEC @ReturnCode = msdb.dbo.sp_add_jobserver @job_id = @jobId, @server_name = N'(local)’
IF (@@ERROR <> 0 OR @ReturnCode <> 0) GOTO QuitWithRollback
COMMIT TRANSACTION
GOTO EndSave
QuitWithRollback:
IF (@@TRANCOUNT > 0) ROLLBACK TRANSACTION
EndSave:
GO

If you execute this job as is, you should see the following:

Success! Or is it?

But you will never get the email!

Modify the above job and replace the line:

@command=N’exec Send_test_email_Query_attached’,

with

@command=N’exec Send_test_email’,

Now if you run the job, it will fail!

This time it clearly failed!

But as is usual with sp_send_dbmail, the error message isn’t overly helpful:

Executed as user: NT AUTHORITY\SYSTEM. Failed to initialize sqlcmd library with error number -2147467259. [SQLSTATE 42000] (Error 22050). The step failed.

But it does help give a clue. The problem seems to be some sort of permissions issue. So I’ll admit, at this point I tried all sorts of solutions, including setting up a proxy user, giving unfettered rights to my SQL Agent user and other things (thinking once I got it working I could then lock things back down). Instead, I found a much easier solution buried in a thread on the Microsoft site.

You’ll note when I wrote the original stored procedure I fully qualified the table name. This is often generally useful, but here I did it because I was cheating and knew I’d need it for this demo.

The solution is actually VERY simple and I’ll show it both graphically and via a script.

First: change the database to MSDB and then fully qualify your call to the stored procedure as below:

Execute it from the MSDB database

However, there’s one more critical step: under the ADVANCED tab in the step change the Run As User to dbo:

Seems simple, but it’s critical

Now if you script out the scheduled task it should look like:

USE [msdb]
GO

/ Object: Job [Send AdventureWorks Email] Script Date: 7/27/2021 9:26:37 AM /
EXEC msdb.dbo.sp_delete_job @job_id=N’08a55e18-eecf-4d4c-8197-8135a0d7520b’, @delete_unused_schedule=1
GO

/ Object: Job [Send AdventureWorks Email] Script Date: 7/27/2021 9:26:37 AM / BEGIN TRANSACTION DECLARE @ReturnCode INT SELECT @ReturnCode = 0 / Object: JobCategory [[Uncategorized (Local)]] Script Date: 7/27/2021 9:26:37 AM /
IF NOT EXISTS (SELECT name FROM msdb.dbo.syscategories WHERE name=N'[Uncategorized (Local)]’ AND category_class=1)
BEGIN
EXEC @ReturnCode = msdb.dbo.sp_add_category @class=N’JOB’, @type=N’LOCAL’, @name=N'[Uncategorized (Local)]’
IF (@@ERROR <> 0 OR @ReturnCode <> 0) GOTO QuitWithRollback

END

DECLARE @jobId BINARY(16)
EXEC @ReturnCode = msdb.dbo.sp_add_job @job_name=N’Send AdventureWorks Email’,
@enabled=1,
@notify_level_eventlog=0,
@notify_level_email=0,
@notify_level_netsend=0,
@notify_level_page=0,
@delete_level=0,
@description=N’No description available.’,
@category_name=N'[Uncategorized (Local)]’,
@owner_login_name=N’sa’, @job_id = @jobId OUTPUT
IF (@@ERROR <> 0 OR @ReturnCode <> 0) GOTO QuitWithRollback
/ Object: Step [Send email] Script Date: 7/27/2021 9:26:37 AM /
EXEC @ReturnCode = msdb.dbo.sp_add_jobstep @job_id=@jobId, @step_name=N’Send email’,
@step_id=1,
@cmdexec_success_code=0,
@on_success_action=1,
@on_success_step_id=0,
@on_fail_action=2,
@on_fail_step_id=0,
@retry_attempts=0,
@retry_interval=0,
@os_run_priority=0, @subsystem=N’TSQL’,
@command=N’exec adventureworks2014.dbo.Send_Test_Email_Query_attached’,
@database_name=N’msdb’,
@database_user_name=N’dbo’,
@flags=0
IF (@@ERROR <> 0 OR @ReturnCode <> 0) GOTO QuitWithRollback
EXEC @ReturnCode = msdb.dbo.sp_update_job @job_id = @jobId, @start_step_id = 1
IF (@@ERROR <> 0 OR @ReturnCode <> 0) GOTO QuitWithRollback
EXEC @ReturnCode = msdb.dbo.sp_add_jobserver @job_id = @jobId, @server_name = N'(local)’
IF (@@ERROR <> 0 OR @ReturnCode <> 0) GOTO QuitWithRollback
COMMIT TRANSACTION
GOTO EndSave
QuitWithRollback:
IF (@@TRANCOUNT > 0) ROLLBACK TRANSACTION
EndSave:
GO

If you then execute THIS scheduled task you’ll get both a success message:

And you should actually receive the email with the query results attached.

So, basically an issue that surprised me that it even existed, actually ended up with a fairly simple solution.
